In addition, you may check Module Connection settings (2). In most cases, it needs you only to set an IP-address of the gateway (1). Step 2) Configure new PLX31-EIP-SIE module instance in Studio 5000. If you cannot find it there then you should download and install EDS files from Prosoft Technology PLX31-EIP-SIE product’s web page: You can find it in Communication Adapter subcategory filtered by Prosoft Technology Vendor. Step 1) Add new module to the Ethernet subnet – Prosoft PLX31-EIP-SIE industrial gateway. Step 0) Create a new project in Studio 5000 based on 1769-元6ERM 5370 CompactLogix controller.
#Clp siemens step 7 300 how to
You will not need to write a bit of code on Siemens side.īelow I will show you step-by-step how to do this in real application examples based on experience from my latest project: In this article I will show you how to use their PLX31-EIP-SIE gateway to make a connection for data exchange between Ethernet/IP and Industrial Ethernet protocols.įor it to work, you will need to write a small amount of code on the A-B Logix side only, and set the appropriate gateway configuration for your application. Prosoft Company has a lot of different gateways, almost for all existing types of industrial networks and protocols.
Of course, you can write you own code on both AB and Siemens sides using, for example, a Modbus TCP protocol. However, the fastest way is to use an Industrial Gateway. There is a really big problem for automation engineers to “shake hands” between AB and Siemens PLCs, when it is necessary to send or receive data to/from AB Logix PLC and Siemens Simatic S7 PLC. In this article I'll walk you through how to setup a connection between an Allen Bradley CompactLogix 1769-元6ERM controller, and a Siemens Simatic S7-300 PLC CPU 315-2PN/DP via Ethernet using the Prosoft PLX31-EIP-SIE Gateway.
